Die Formed Wire Mesh
Our Die Formed Wire Mesh has many applications such as packer elements, back-up rings, case seals, scrapers filters, and high-temperature seals. UTEX also has a process (#4219204) whereby knitted wire mesh is molded in conjunction with homogeneous rubber or other materials to act as an anti-extrusion device. Our 80 years of industry experience has produced thousands of products for our customers and unique specific materials to withstand the most extreme conditions.
Don't see what you're looking for? Let us know.
Contact Us
-
Applications & Materials
- Wire mesh process increases temperature range from 400F – 750F.
- Seals can also be protected against extrusion by reinforcing corners with fabric across the e-gap, the surface area of the seal cannot increase to push through.
- Fabric can act similarly to springs by preventing rubber from extruding into gaps when under pressure but can do so at a much lower price.
-
Wire Mesh End Element
-
Wire Mesh Packer
-
P-Seal
-
P-Seal Cross Section
-
-
Styles & Descriptions:
Style 180- Graphite & .0045″ Wire Diameter
- 304 SS
- Approx. 50% wt. graphite
Style 181- Graphite & .0045″ Wire Diameter
- Copper
- Approx. 50% wt. graphite
Style 182- Aramid Yarn & .008″ Wire Diameter
- 316 SS
- Approx. 25% wt. aramid
-
Style 183
- Graphite & .0045″ Wire Diameter
- 316 SS
- Approx. 40% wt. graphite
Style 184- Aramid Yarn, PTFE & .008″ Wire Diameter
- 316 SS
- Approx. 9% wt. aramid, 65% wt. PTFE
Style 189- 5% Phosphorus Bronze & .011″ Wire Diameter
-
Style 190
- .0045″ Wire Diameter
- 304 SS
Style 191- .0045″ Wire Diameter
- Copper
Style 192- .011″ Wire Diameter
- 304 SS
Style 193- .011″ Wire Diameter
- Copper
-
Style 194
- .011″ Wire Diameter
- 316 SS
- Metal Specs Certifiable
Style 195- .0045″ Wire Diameter
- 316 SS
Style 196- .014″ Wire Diameter
- 316 SS
Style 197- .011″ Wire Diameter
- Inconel 600
